NO RESERVE TEMPO PE930 TELEPHONE TEST SET!!!




Tempo (Progressive) PE930 Telephone Test Set with Adjustable Ringer

Tempo (Progressive) PE930 Telephone Test Set with Adjustable Ringer

We accept all major credit cards!! Call the office on +44 (0)1842 767947 to process your trasaction using any of the below forms of payment.....




Forget everything you've previously considered a "must have" in a professional quality telephone test set - Progressive Electronics has set a new standard. Their new series of telephone test sets offer technicians at every level the functions, features, and quality they need in this ever-changing world of communications. With leading edge designs in every aspect of these new models, you'll soon realize what we mean by "Gone to Extremes".

  • Award Winning Waterproof Design (IEC 60529 IP67 Rated)

  • Tone and Pulse Dial

  • Built-In Ringer with Adjustable Ring Tones

  • 10 Number Speed Dial Memory (32 Digits Each)

  • Last Number Re-Dial

  • Precise Hook Flash

  • Microphone Mute

  • Easy to Use Talk and Monitor Keys

  • Audible and Visual Mode Indicators

  • Polarity Test in Any Mode

  • Low Battery Indicator

  • Drop Tested to 20 Feet

  • Digital Safe Monitor

  • Automatic Ground Start Operation (optional ground start wire kit available)

  • Unique 'Quick Release' Belt Clip

  • Premium Cordset with Bed-of-Nails and Piercing Pin Clips

What does "waterproof" mean?
Progressive takes the hype out of common phrases like "rain proof" and "splash safe"  with their revolutionary new case designs. In the test equipment world, water is the  worst enemy, so they have a tough standard for the word "waterproof". Progressive's telephone  test sets are proof tested to an IEC IP67 rating. Meaning, these units will not only  withstand a monsoon rain, they can actually be submersed in water for a period of  time. (It isn't likely for that to occur because all models will actually float!) Progressive's new plastics even won the Modern Plastics International Design Award for Electronics.

Why DigAlert™
When working around telephone wiring, the chance that you will encounter digital service lines increases every day. An ordinary telephone test set can damage digital service lines or at the very least, knock them out of service for a while. With DigAlert protection you don't have to worry about accidentally intruding into digital services like ADSL, ISDN, T-1 and other high capacity circuits. Progressive has even incorporated a unique over-voltage alarm and lockout feature in case you accidentally connect to a DSL power feed.

LINE ELECTRICAL

Maximum Loop Length 5k ohm
Minimum Loop Current 10mA
Maximum Off-hook Resistance 300 ohm
Minimum DC Resistance in Idle, Monitor and Lockout 10M ohm at 300 VDC
Minimum AC Impedance in Monitor 400k ohm at 1 kHz
Line High-DC Lockout Range 120 VDC minimum
450 VDC maximum

DIAL SIGNALING

Pulse (rotary) Dial
  Pulse Rate
  Break Proportion
  Break Interval Resistance
  Inter-digital Interval
10 pulse per second
60%
1M ohm
800µs
Dual-tone Multifrequency (DTMF) Level -3 dBm nominal
Flash (Time-break Recall) Duration 600µs nominal
Speed Dial Capacity
  Stored Numbers
  Stored Number Length
10
32 digits per storage #
Programmed Pause Duration 4 seconds per key press

BATTERY OPERATION

9 VDC Alkaline Battery Operating Life 3 months of typical use
30 hours of continuous loudspeaking
Auto Battery Saver (with warning tone)
  Power Off When No Line DC
  Power Off With Line DC
90 seconds
20 minutes

ENVIRONMENT

Operating Temperature -24°C to 60°C
-29°F to 140°F
Storage Temperature -50°C to 75° C
-58°F to 167°F
Dust and Water resistance IP67 per IEC 60529
Physical Shock TRY-TSY-000344 Bellcore
